Product Description:

Nominal Voltage: 0.6/1KV

Conductor:  Class 2 plain annealed copper, strand copper

Conductor nominal cross section area: 1.5sqmm, 2.5sqmm

Cores: 2C~50C+E

Insulation: V-90 PVC

Insulation color: white with black number + green/yellow, or black with white number + green/yellow

Armore (optional): steel wire armore

Sheath: 5V-90 PVC

Sheath color: Orange, or as per requirement

Max. operating temperature: 90℃

Package: wooden drum, or as per requirement

Main product model: PVC control cable

Product standard: AS/NZS5000.1

Product characteristics:

High mechanical strength resistance (armored type), High temperature resistance, low temperature resistance, flame retardant and high electrical conductivity, also fire resistance, UV resistance or Rohs compliant can be available as per request.

Product application:

For control circuits unenclosed, enclosed in conduit, buried direct or in underground ducts for commercial, industrial, mining and electricity authority systems where not subject to mechanical damage (unarmored type) or where mechanical damage may occur (armored type), also suitable for glanding.

Product parameter:  (more details please email us: info@himakecable.com)
