China factory sale Australia fire rated cable ASNZS3013
- China factory sale Australia fire rated cable ASNZS3013
- Rated voltage: 450/750V
- Conductor: Oxygen free plain copper wire, class 2 conductor type
- Insulation: Mica-glass tape flame barrier + X-HF-110
- Shield: PET tape + Al. Foil + naked tinned copper strands earth core
- Sheath: HFS-110-TP
- Max. operating temperature: 110℃
- Package: 100 meters per roll, or 500 meters per reel, or wooden drum, or as per requirement
- Product standard: AS/NZS 5000.2, AS/NZS 3013 - WS52W
- Certificate: SAA
- Leat time: 15~25 working days, it depends the order quantity
- Price term: FOB, CFR, CIF,EX-Works
- Payment term:T/T,LC at sight,West Union
- MOQ:10000 meters, trial order can be available.
- Shipment: Express, FCL, LCL, by sea or by air
Product Description:
China factory sale Australia rated cable ASNZS3013
Nominal Voltage: 450/750V
Conductor: Oxygen free plain copper wire, class 2 conductor type
Conductor nominal cross section area: 0.75~4.0 sqmm
Cores: 2C,4C, 2C+E
Insulation: Mica-glass tape flame barrier + X-HF-110
Insulation color: 2C:red + white; 4C: red + white + blue + black; 2C+E: red + white + naked earth
Shield: PET tape + Al. Foil + naked tinned copper strands earth core
Sheath: HFS-110-TP
Sheath color: Red or as per requirement
Max. operating temperature: 110℃
Package: 100 meters per roll, or 500 meters per reel, or wooden drum, or as per requirement
Main product model: Screened HF-110 fire rated cable, Shielded Fire resistance cable
Product standard: AS/NZS 5000.2, AS/NZS 3013 - WS52W
Product characteristics:
Low smoking Halogen free, Fire resistance,UV resistance, Rohs compliant
Product application:
For inclusion in wiring systems required tomaintain circuit integrity under fire conditions. Wiring systems can beassociated with firefighting, evacuation, emergency equipment, essential servicesand other safety functions in buildings, oil rigs, ships, and other structures.
Product parameter: (more details please email us: info@himakecable.com)
|
Cores and conductor size (mm2） |
Conductor |
Insulation thickness (mm) |
Earth core |
Sheath thickness (mm) |
Approx. O.D. (mm) |
|
2×0.75 |
OFC |
0.7 |
TC |
1.2 |
9.5 |
|
2×1.5 |
OFC |
0.7 |
TC |
1.2 |
9.9 |
|
4×1.5 |
OFC |
0.7 |
TC |
1.2 |
11.7 |
|
2×0.75+E |
OFC |
0.7 |
TC |
1.2 |
9.8 |
|
2×1.5+E |
OFC |
0.7 |
TC |
1.2 |
10.2 |
|
4×1.5+E |
OFC |
0.7 |
TC |
1.8 |
13.0 |
Product Advantages:
1. The conductor is made of new pure annealed copper, ensuring a good electrical properties and a very good conductivity.
2. We are a very professional cable manufacturer with advanced production equipments and strict quality inspection system, ensuring the products complying the standard and customized requirement.
Production equipments
Products Quality inspection
3. We have more than 10 years' export experience and exported products to more than 60 countries over the world with a good reputation internationally and SAA certificate.
4.We not only offer good products and good service to our customers, but also try to develop our staffs, offer a good trainning, good working and living conditions to the staffs.
5. Also we are a company with highly social reponsibility, often take part in public benifits activities, like tree planting, green environment activities, aiding poor students and the people in difficult condition to achieve their dreams,etc.
