Silicone Rubber insulated and sheathed flexible cable H05SS-F H05SST-F 300/500V
- Rated voltage: 300/500V
- Conductor: wires of annealed copper, plain or tinned
- Insulation: Silicone rubber
- Insulation color: as per HD308/UNE 21089-1
- Sheath: Silicone rubber,a polyester fiber braid added for H05SST-F type
- Sheath color: normally black
- Operating temperature: -60℃~180℃
- Standard: TS HD 22.15.S1
- Certificate: CCC,CE,CB,BS,SAA,SGS
- Leat time: 15~25 working days, it depends the order quantity
- Price term: FOB, CFR, CIF,EX-Works
- Payment term:T/T,LC at sight,West Union
- MOQ:10000 meters, trial order can be available
- Shipment: Express, FCL, LCL, by sea or by air
Product Description：
Rated voltage: 300/500V
Conductor: wires of annealed copper, plain or tinned, Class 5 flexible type conductor
Insulation: Silicone rubber
Insulation color: 2C: blue+brown, 3C: blue+brown+green/yellow, 4C: brown+black+grey+green/yellow, 5C: blue+brown+grey+black+green/yellow, as per HD308/UNE 21089-1
Sheath: Silicone rubber, a polyester fiber braid added for H05SST-F type
Sheath color: normally black, comments: cables for permanent outdoor use only in black color. Please consult for different colors.
Package: 100 meters per roll, polywooden drum, wooden drum or as per requirement
Operating temperature: -60℃~180℃
Standard: TS HD 22.15.S1
Product characteristics:
Resistant to very high temperature or low temperature, Resistant to Ozone, oxygen, UV rays and good water and rain resistance.Product application:
Control and power supply cable for the machinery and facilities operating in high temperature environments: Steelworks, glassworks, nuclear, marine, oven, steam ovens, projectors, welding equipment etc...) where high mechanical strength is required.
Product parameter: (more details please email us: info@himakecable.com )
|
Cross-section (mm²) |
Insulation thickness (mm) |
Sheath thickness (mm) |
Approx. O.D. (mm) |
Max. Permissible Current at 170°C (Amp.) |
|
2×0.75 |
0.6 |
0.8 |
6.2 |
5.4 |
|
2×1.0 |
0.6 |
0.9 |
6.7 |
7.0 |
|
2×1.5 |
0.8 |
1.0 |
7.9 |
9.4 |
|
2×2.5 |
0.9 |
1.1 |
9.3 |
12.2 |
|
3×0.75 |
0.6 |
0.9 |
6.8 |
5.1 |
|
3×1.0 |
0.6 |
0.9 |
7.1 |
6.7 |
|
3×1.5 |
0.8 |
1.0 |
8.4 |
9.0 |
|
3×2.5 |
0.9 |
1.1 |
9.9 |
11.6 |
Product Advantages:
1. The conductor is made of new pure annealed copper, ensuring a good electrical properties and a very good conductivity.
2. We are a very professional cable manufacturer with advanced production equipments and strict quality inspection system, ensuring the products complying the standard and customized requirement.
Production equipments
Products Quality inspection equipments
3. We have more than 10 years' export experience and exported products to more than 60 countries over the world with a good reputation internationally.
4.We not only offer good products and good service to our customers, but also try to develop our staffs, offer a good trainning, good working and living conditions to the staffs.
5. Also we are a company with highly social reponsibility, often take part in public benifits activities, like tree planting, aiding poor students, green environment activities, etc.
