UTP Cat5e cable CCA BC conductorUTP Cat5e cable CCA BC conductorUTP Cat5e cable CCA BC conductorUTP Cat5e cable CCA BC conductor

UTP Cat5e cable CCA BC conductor

  • Conductor Size: 0.51mm, 24AWG
  • Conductor Material: CCS+CCA/CCA/CCU/BC
  • Nuber Of Conductor: 4~50 pairs
  • Insulation Material: PE, HDPE
  • Jacket Material: PVC, ROHS PVC, LSZH
  • Operating Temperation: -40 °C - +75 °C
  • Package: 305 meters per box or as per requirement
  • Main product model: Cat5e, HSYV5e, HSYY5e, HSYZ5e
  • Product standard: ISO/IEC11801, IEC61156-2, YD/T1019-2001, ANSI/TIA/EIA-568B, UL444
  • Certificate: CCC,CE,UL,FCC,ISO,ROHS,SGS
  • Leat time: 15~25 working days, it depends the order quantity
  • Price term: FOB, CFR, CIF,EX-Works
  • Payment term:T/T,LC at sight,West Union
  • MOQ:10000 meters, trial order can be available.
  • Shipment: Express, FCL, LCL, by sea or by air

Product Description:


CAT5E 4 PAIRS


Product Description:

Conductor: CCS+CCA/CCA/CCU/BC

Conductor size: 0.51mm, 24AWG

Twist pairs: 4~50 pairs

Insulation: PE, HDPE

Insulation color: 4 pairs color: Blue/white-blue; Green/white-green; Orange/white-orange; Brown/white-brown, color coded according to ANSI/TIA/EIA-568-B color code

Sheath: flame retardant PVC Rohs compliant, LSZH compound

Sheath color: white, grey, blue or as per request

Package: 305 meters per box or as per requirement

Main product model: Cat5e, HSYV5e, HSYY5e, HSYZ5e

Product standard: ISO/IEC11801, IEC61156-2, YD/T1019-2001, ANSI/TIA/EIA-568B, UL444


Product characteristics:

UV resistance and Rohs compliant; Feature different strand lay-length, keeping good NEXT and FEXT, anti-electromagnetic disturbing improvement; Structure CCS+CCA/CCA/CCU/BC conductor, HDP/PE insulation, FRPVC/LSOH PVC jacket, twinning structure, flexible added, easily cabling; High-performance data transmission.


Product application:

The cables transmission frequency up to 100MHz, used as cabling among the cross-connecting box and the communication output and of the operation area or between main distribution frames in the commercial building comprehensive wiring system and residential comprehensive wiring system, support 100BASE-T4/TX(FAST Ethernet), 100VG-AnyLAN Fast Ethernet, 1000Base-T Gigabit Ethernet, 1000Base-TX Gigabit Ethernet, 155Mbps, 622Mbps.


Packae datas: (more details please email us: info@himakecable.com)

Product

Type

Describtion

Norminal Cross-section

(mm)

Wire core Structure

(No./mm)

Insulationl Diameter

(mm)

Calculation Outer Diameter

(mm)

Product  prox. Weight

(Kg/km)

Cat.5e UTP PVC

4x2x0.5(24AWG)

1/0.51

0.91

5.1

31

Cat.5e UTP PVC

25x2x0.5(24AWG)

1/0.51

0.91

11.5

175

Cat.5e UTP LSZH

4x2x0.5(24AWG)

1/0.51

0.91

5.1

33

Cat.5e UTP LSZH

25x2x0.5(24AWG)

1/0.51

0.91

11.5

179

 PACKAGE



STOCK
